DYZ-016 Column Type Load Cell 50 ton

SUPPORT
DatasheetWiring Diagram

Stock

Out of Stock| Available on backorder

Order Product

$725.00 NZD
$725.00 NZD
Sale Sold out



The DYZ-016 Column Type Load Cell is a robust and versatile force sensor designed for heavy-duty weighing applications in various industrial settings. Its simple structure, high accuracy, and reliable performance make it an ideal choice for a wide range of applications, including rail weighbridges, bucket scales, platform scales, and other electronic weighing equipment.

Key Features

  • Simple Structure: Cost-effective and easy to integrate.
  • High Accuracy: Provides precise and reliable force measurements.
  • Durable Construction: Made of stainless steel for reliable performance in various environments.
  • Versatile Applications: Suitable for various industries and applications, including rail weighbridges, bucket scales, and platform scales.
  • Improved Sealing: The sealing diaphragm design enhances sealing performance and prevents damage to the sensor shell.

Technical Specifications

Parameter Value
Range 0-50T
Material Stainless Steel
Output Sensitivity 1.5-2.0mV/V
Impedance 350/700Ω
Zero point output +2%FS
Non-linearity 0.5%FS
Hysteresis 0.5%FS
Repeatability 0.5%FS
Creep (30 min) 0.05%FS
Temperature sensitivity drift 0.05%F.S./10°C
Zero point Temperature drift 0.05%F.S./10°C
Insulation Resistance ≥5000MΩ/100VDC
Service voltage 5-15V
Operating Temperature Range -20-65°C
Safe overload 150%
Extreme overload 200%
Cable line specifications Φ5x2m
Cable limit tension 10kg
Response frequency 10kHz

Dimensions
